| Model | MPS14 | MPS22 | MPS30 | MPS34 |
| Production at 130%(g/h,3000PPM) | 14.0 | 22.0 | 30.0 | 34.0 |
| Production at 130% (g/h, 1800PPM) | 10.0 | 16.0 | 23.0 | 25.0 |
| Production at 100% (g/h, 3000PPM) | 11.0 | 17.0 | 23.0 | 26.0 |
| Salt Level (g/L) | 1.8 ~ 5 (recommended 3g/L) |
| Advised pool volume (m³)*( at 3000PPM ) | 20-50 | 35-75 | 45-100 | 60-120 |
| Power Supply | 100~240V 50/60Hz |
| Max Power Consumption (W) | 116 | 170 | 196 | 223 |
| Operating Temperature (°C) | -5 ~ 42 |
| Salinity Test | Salt Level Detection (accuracy ±500PPM) |
| Self-cleaning | Default 4h,3 options in total (2/4/6h) |
| Dosing Pump | Built-in / External |
| Communications | MODBUS RS485 / Wi-Fi / Dry Contact |
| Control Unit Dimension LxWxH (mm) | 270 x 205 x 75 |
| ELECTROLYSIS CELL |
| Water Connection (mm) | 63 / 60.3 / 50 / 48.3 |
| Water Temperature (°C) | 10 ~ 40 |
| Maximum Pressure (Bar) | 3 |
| Cell Life (h) | 12,000 |
| PACKAGING SPECIFICIATIONS |
| Net weight (kg) | 7.6 |
| Gross Weight (kg) | 8.9 |
| Packaging Dimension LxWxH (mm) | 550 x 400 x 300 |
